TJCL25 2.5T Tilt Jib (Long)
| Product | Code |
|---|---|
| 2.5Tonne SWL Tilt Jib (Long) | TJCL25 |
The type TJCL2.5 Tilt Jib (Long) is the most versatile Forklift Jib attachment in our range, allowing extra height to 2.48 metres, with a 3.58 metre reach when fully extended. This slip-on attachment is held to the Forklift by a safety chain. The Jibs overall length when closed is 2.15 metres. The standard finish on the type TJCL2.5 Tilt Jib (Long) is Zinc Plated.
SPECIFICATIONS:
• Safe Working Load (SWL) 2500kg Max.
• Unit Weight 180kg
• Load Centre 1005mm
• Pocket Size 165 x 65
• Pocket Centres 337 mm
• Horizontal C of G 1010mm
• Vertical C of G 225mm
|
TJCL25 Fixed Jib |
Safe Working Load (SWL) per position |
|||||||
|
Position |
1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
|
Extension (mm) |
1005 |
1465 |
1925 |
2060 |
2440 |
2820 |
3200 |
3580 |
|
SWL (kg) |
2500 |
2500 |
1900 |
1650 |
1250 |
650 |
380 |
240 |
