Stainless Steel Dee Shackles
Stainless Steel Dee Shackles.
Eye Nut DIN 582 are generally used as a removable lifting point where a rated nut can be utilised. Also can be used as a termination for chain, wire rope and other assemblies where required.
• Made from C15 carbon steel with zinc plated finish,manufactured with a standard larger eye. Only availablein metric thread sizes.
• Conforms to DIN 582, marked with working load limit in tonne, nominal size in millimetre, quality grade, batch numbered and supplier identification.
• Proof tested to 2 x working load limit and minimum breaking force of 6 x working load limit.
• Test certificates are available upon request.
|
||||||
| CODE |
A(mm) |
B(mm) | D(mm) | L1(mm) | L2(mm) | B.L(kg) |
| SS-360F-05 | 4.8 | 10.8 | 9.8 | 18 | 30 | 1000 |
| SS-360F-06 | 5.8 | 13.5 | 12 | 21 | 36 | 1700 |
| SS-360-07 | 6.8 | 14.5 | 13.5 | 24.2 | 41.3 | 2000 |
| SS-360F-08 | 7.6 | 17.3 | 15.9 | 29.7 | 48.2 | 2500 |
| SS-360F-10 | 9.7 | 22.5 | 20 | 35.7 | 60 | 4100 |
| SS-360F-12 | 11.6 | 27 | 23.7 | 43.1 | 70 | 5400 |
| SS-360-16 | 16 | 32 | 31.8 | 56 | 95 | 10000 |
| SS-360-19 | 19 | 38 | 37.6 | 66 | 110 | 15000 |
| SS-360-25 | 24.7 | 50.4 | 49.7 | 87 | 148.7 | 23000 |
| SS-360-32 | 31.2 | 64.4 | 64.4 | 110.1 | 190 | 26000 |
