WP-NC2RA 6 Person Crane Cage + Roof
| Product | Code |
|---|---|
| 6 Person + Roof | WP-NC2RA |
WP-NC2RA 6 Person Crane Cage + Roof.
The WP-N2CR Crane Cage has been designed in strict accordance with Australian Standard AS1418.17 to elevate up to 6 personnel where it is not practicable to erect scaffolds or use a specially designed device.
FEATURES:
- Suitable for a maximum of 6 people
- Fitted with mesh roof for overhead protection
- Fitted with mesh sides to prevent objects falling off the platform
- 8 (eight) harness Anchor Points
- Hand Rails
- Supplied with Lifting Chains
- Fork Arm slippers are provided for transport purposes only
- Work performed in this cage shall be limited to special tasks of short duration
- Load Test Certificate, Risk Control Measure documents, Work Cover registration and comprehensive instructions supplied
- Zinc finish
SPECIFICATIONS:
| Maximum Capacity | 6 people |
| Working Load Limit (WLL) | 750kg |
| Dimensions | 2400 x 1200mm |
| Unit Weight | 500kg |
** It is a mandatory requirement of AS1418.17 that suspension sling sets are supplied as an integral component of a personnel crane cage. If you are using or are offered a cage without dedicated chains or slings, that cage does not comply with Australian Standards and Design Registration requirements and should not be considered for the use of hoisting personnel**
