Tube ends

Part number Tube outer diameter (OD) x Wall thickness
(mm)
Application Thread size c (mm) Shank length a (mm) Head thickness b (mm) Thread stop (mm) Max static load (mm) Housing profile Material Thread material

Round threaded



RETi-5825 20 x 1.6 foot or castor M8 36.0 5.0 38.0 300 G nylon mild steel ZP
RETi-5827 22 x 1.6 foot or castor M8 36.0 5.0 38.0 300 G nylon mild steel ZP
RETi-5826 30 x 1.6 foot or castor M10 36.0 5.0 38.0 300 G nylon mild steel ZP
RETi-5892 32 x 1.6 foot or castor M8 35.0 5.0 35.0 300 G nylon mild steel ZP
RETi-5824 35 x 1.6 foot or castor M10 34.0 5.0 36.0 300 G nylon nylon
RETi-5875 50 x 2.0 foot or castor M10 32.0 5.0 37.0 300 G nylon mild steel ZP
RETi-5874 50 x 1.6 foot or castor M12 32.0 5.0 37.0 300 G nylon mild steel ZP
RETi-5838 60 x 2.0 foot or castor M10 35.0 5.0 33.0 300 G nylon mild steel ZP

Round plain (no thread)



Part number Tube outer diameter (OD) x Wall thickness
(mm)
Shank length a (mm) Head thickness b (mm) Material
RTRi-5506 25 x 1 = 3 11.5 5.0 polyethylene (PE)
RTRi-5509 30 x 0.8 = 2.5 11.5 5.0
RTRi-5508 30 x 0.8 = 2.5 11.5 5.0
RTRi-5578 33.7 x 2.6 = 4 15.0 5.5
RTRi-5507 38 x 1 = 2 11.5 5.0
RTRi-5580 42.4 x 2.6 = 4 17.5 7.5
RTRi-5582 48.3 x 3.2 = 5 19.0 8.0
RTRi-5515 50 x 1 = 2.5 11.5 5.0
RTRi-5516 50.8 x 1 = 2 11.5 5.0
RTRi-5584 60.3 x 3.2 = 5 20.5 10.0
RTRi-5586 76.1 x 3.2 = 5 22.0 13.0

Tube sliders

Telescopic tube slider accessories



Part number for 1 kit (includes 2 pieces) Function Material Retail pack Qty
SPTUBE50-40 1 kit to telescope 40 x 40 x 2 SHS inside 50 x 50 x 2 SHS nylon 20
